20CrMnMo forged steel round bar

39 Views
29-May-2024

KUNFENG offer 20CrMnMo forged steel round bar and 20CrMnMo alloy steel round bar with good quality and fast delivery at best price. And we are always keep complete specifications 20CrMnMo round bar stock for our customers choose. Welcome to visit our factory!

20CrMnMo round bar Chemical analysis -% by mass*

Grade	C	Si	Mn	P	S	Cr	Ni	Cu	Mo
Grade	max	max	max	max.	max.	max	max	max	max
20CrMnMo	0.17-0.23	0.17-0.37	0.90-1.2	0.035	0.035	1.10-1.40	0.030	0.030	0.20-0.30

20CrMnMo round bar Merchanical Propertites

Grade	Tensile Strength (Mpa)	Yield Strength (Mpa)	Elongation in 100-150 mm(%)	percentage reduction of area	Impact(Akv(J)	impact strength	Hardness
20CrMnMo	≥1180(110)	≥885	≥10	≥45	55	≥49	≤217HB

specifications:

Standard: DIN 7527-6,EN 10204, EN 10228-3,EN 10250,N10083,SEW 550
Diameter: 5mm-1200mm ,the forged round bar is from 80mm-1200mm:
Length: 1000-12000mm
Inspecting: SEP1921 CLASS C/C，D/D，E/E

20CrMnMo forged steel round bar Tolerance: OD: 0/+3.0mm Length: 0/+20.0mm Straightness: 3mm/1000mm

Delivery Condition: Hot forged +Normalized+ Rough turned
Q/T:Quench+ Temper Annealing
Steelmaking Process: electric furnace + LF refining furnace + argon protection casting + VD vacuum degassing furnace ingot (bottom gating)

We are a 20CrMnMo forged round bar manufacturer, can offer in carbon, alloy, stainless steel round bars, Our Company through quality, environment, occupational health and safety management system, etc. Products have passed the ISO9001:2000 quality management system certification, China CCS, South Korea KR, Italy RINA, Japan NK, France BV, the United States ABS, Russia RS, Lloyd's LR, Germany Lloyd's GL classification society certification.
