ABS Grade A Shipping Steel Plate

124 Views
13-Jul-2024

ABS Grade A steel plate with good toughness properties, higher strength. ABS Grade A steel plate are mainly used to contribute hull of ships and vessels in low temperature oceans. All of KUNFENG stock is the high quality ABS Grade A shipbuilding steel plate. And KUNFENG has a large number of stocks. We cooperate with many companies and factories from all over the world.

ABS GRADE A steel plate work Strength Chemical Composition Analysis

ABS GRADE A General Strength Chemical Composition
Grade	The Element Max(%)
Grade	C	Si	Mn	P	S	N
ABS GRADE A	0.21	0.50	2.5*C	0.035	0.035	0.02

Crack Sensitivity: Pcm=(C+Si/30+Mn/20+Cu/20+Ni/60+Cr/20+Mo/15+V/10+5B)%
Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%

steel plate for sale

ABS GRADE A steel plate work Strength Property Analysis

ABS GRADE A General Strength Property
Grade		Mechanical Property			Charpy V Impact Test
Grade	Thickness	Yield	Tensile	Elongation	Degree	Energy 1	Energy 2
ABS GRADE A	mm	Min Mpa	Mpa	Min%	20	J	J
	t≤50	235	400-520	18%		-	-
	50＜t≤70	235	400-520	18%		24	34
	70＜t≤100	235	400-520	18%		27	41
	Note: Energy 1 is transverse impact test, Energy 2 is longitudinal

Equivalent steel grade of ABS GRADE A

DNV	GL	LA	LR	BV	CCS	KR	RINA
NVA	GL-A	LR/A	LR-A	BV/A	CCS/A	KA	RI/A

KUNFENG Steel keeps more than 10,000 tons hot rolled and cold rolled ABS Grade A steel plate in stock each month. We can meet our customer's any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure. We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find ABS Grade A steel plate exporter, please contact KUNFENG sales team. We will give you the ABS Grade A steel plate good quality and best service from us.
