S355J2G2W Atmospheric corrosion resistant steel

S355J2G2W Atmospheric corrosion resistant steel

S 355 J2G 2W Chemical composition, S 355 J2G 2W Mechanical properties S355J2G2W steel grade is a hot rolled products of structural steels in technical delivery conditions with improved atmospheric corrosion resistance, which is widely use in Mine fans, earth moving buckets, trailers etc.

Category: Weather Resistant Steel
Hits: 483
Updatetime: 21-Aug-2023

S355 J2G 2W atmospheric corrosion resistant steel Chemical composition, S 355 J2G 2W Mechanical properties S355J2G2W steel grade is a hot rolled products of structural steels in technical delivery conditions with improved atmospheric corrosion resistance, which is widely use in Mine fans, earth moving buckets, trailers and large road vehicles, drill rings, cranes, excavators, underground mining equipment, bridges and other high strength components requiring superior toughness.

S355J2G2W Atmospheric corrosion resistant steel plate:

                 S355J2G2W steel Chemical composition%

Grades

C max

Si max

Mn

P max

S max.

Cu max

Cr max

Al Min

Ni max

Mo max

Nb

S355J2G2W

0.16

0.50

0.50-1.50

0.035

0.030

0.25-0.55

0.40-0.80

0.02

0.65

0.30

0.015-0.060

               S355J2G2W steel plate Mechanical Properties

Grade

    Min. Yield Strength MPa

Tensile Strength MPa

EN 10155

    Nominal Thickness (mm)

Nominal Thickness (mm)

Thick mm

≤16

>16 ≤40

>40 ≤63

>63 ≤80

>80 ≤100

>100 ≤150

≤3

>3 ≤100

>100 ≤150

S355J2G2W

3555

345

335

325

315

295

410-680

470-630

450-600

KUNFENG international is an outstanding and professional S355J2G2W atmospheric corrosion resistant steel exporter and stockist in china, especially in super thick atmospheric corrosion resistance of structural steel plate. We keep more than 10000 ton S355J2G2W steel in stock, If you need any offer, please contact us at any time.
